Cargo shower Category：Cargo shower

Introduction:：The cargo shower room is the passage for goods to enter and exit the clean room. The clean air filtered by the primary effect and the high-efficiency filter is sprayed out to remove the dust attached to the cargo to control the cleanliness. At the same time, i...

AdvisoryOrdering Hotline:0755-29103270

Consult customer service, we recommend the most suitable purification equipment for you!

Product description

use:

The cargo shower room is the passage for goods to enter and exit the clean room. The clean air filtered by the primary effect and the high-efficiency filter is sprayed out to remove the dust attached to the cargo to control the cleanliness. At the same time, it can also serve as an air lock chamber. Prevents internal and external air convection and stabilizes indoor pressure.

Structural features:

1. The system automatically controls the operation, double electronic interlocking, and has a photoelectric sensor.

2. The cold-rolled steel plate is made in the box body, and the outer surface is electrostatically sprayed; or all stainless steel.

3. Automatic control and voice control system.

4, the inner liner is all stainless steel.

Specifications:

Specification model	HLS-1D-2000	HLS-2D-2000	HLS-2D-2300	HLS-3D-2300
Dimensions (L × W × H) mm	2000×1200×2050	2000×2000×2050	2300×2000×2050	2300×3000×2050
Wind forest size (L × W × H) mm	1200×1060×1880	1200×1860×1880	1500×1860×1930	1500×2860×1930
Number of air changes (times / hour)	420	480	370	360
Wind speed (m/s)	18-30
Number of nozzles	12	24	24	36
Air shower cycle	0-99S adjustable
High efficiency filter efficiency	99.99%＠0.3μm
Box main material	1.2-1.5 mm thick cold-rolled steel sheet surface electrostatic spray, matte white; all stainless steel
Door material and quantity	Stainless steel double door
Door interlocking	When the air is showering, the double doors are locked, and they are usually interlocked. Only one door can be opened.
power supply	Three-phase 380V.50Hz
Fan power (W)	1.5KW	3.0KW	3.0KW	4.5KW
weight	～500kg	～850kg	～880kg	～1300kg
